SW HD 4K PLUS Series • Remote Configuration and Control 27
Command
ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Information Requests
Request information
I
In
X!
•Ausw
X*
•Afmt
X@
•Vmt
X1#]
View selected input
X!
, auto-input
switch mode
X*
, Audio mute
status
X@
, and video mute status
X1#
.
Query model name
1I
SWn•HD•4K
•
PLUS•Series
]
In verbose modes 2 and 3:
Inf01*SWn•HD•4K
•
PLUS•Series
]
Show the switcher model name.
SWn = SW2, SW4, SW6, or SW8.
Query model description
2I
HDMI•SWITCHERn•SUPPORT•4K60
]
In verbose modes 2 and 3:
Inf02*HDMI•SWITCHERn•SUPPORT•4K60
]
Show the switcher signal type,
number of inputs, and 4K support.
SWITCHERn = number of inputs
on the unit (2, 4, 6, or 8).
Query part number
N
60-nnnn-nn
]
Show part number
X3^
of the
switcher.
Query firmware version
Q
X(]
Show firmware build number
X(
,
to the second decimal place.
Example:
Q
1.01
]
View EDID in hex format
E
R
X!
EDID
} X%]
In verbose modes 2 and 3:
X! X%]
View the current EDID assignment
for input
X!
in hexadecimal
(128 or 256 bytes).
X%
= current EDID information in
hex.
View EDID native resolution
E
N
X!
EDID
} X^]
Show native resolution and refresh
rate
X^
of the EDID currently
applied to input
X!
.
Example
E
N
X!
EDID
}
1600x1200 @ 60.0 Hz
]
KEY:
X!
= Input number 1 through the highest numbered input on the unit (2 through 8, depending
on the model)
X@
= Audio mute status 0 = Unmuted, 1 = Muted
X%
= Current EDID information in hex 128 or 256 bytes of raw hex data
X^
= Current EDID native resolution and refresh rate
X*
= Auto-input switch mode
0 = Disabled — Manual switching (default)
1 = User-defined priority mode —
The switcher selects the input to which
the user assigns priority. If no priority is assigned, the switcher selects
the active input with the highest number.
2 = Input memory priority mode —
The switcher selects the most recently
applied input, and retains a history of the order in which active inputs
are connected to the unit. If an active input is removed, the switcher
switches to the most recently prioritized input.
X(
= Auto-input switch mode 2 1-250 = Number of seconds the switcher delays before switching to the
timeout most recently applied input.
0 = Immediate switch (no delay)
X1#
= Video mute status 0 = Unmuted (default), 1 = Muted, 2 = Video and sync muted
X3^
= Switcher part number SW2 HD 4K PLUS: 60-1603-01
SW4 HD 4K PLUS: 60-1604-01
SW6 HD 4K PLUS: 60-1605-01
SW8 HD 4K PLUS: 60-1606-01
