PATHWAY
®
Aluminum Wheelchair Ramp Kit Assembly Manual Page 10 of 40
1
3. PLATFORMS
3.1. INSTALL PLATFORMS
If your configuration does not include a platform, skip to ‘CONNECT RAMP SECTIONS’.
Platform handrails are shown for clarity on how to orient platforms in various
configurations. It is strongly suggested that all platforms and ramps be assembled before
installing handrails (see ‘HANDRAILS section).
3.1.1.
There are three basic platform arrangements (one or more of these arrangements may
be used in an installation). All three require the same procedure for assembly except for
FIG. 3.3 which requires an additional PPPC (PLATFORM TO PLATFORM CONNECTOR).
FIG. 3.1 Straight
FIG. 3.2 L-shaped
FIG. 3.3 U-shaped
Two 5 x 5 platforms shown combined to make a 5 x 10 U-shaped.
FIG. 3.1
FIG. 3.2
FIG. 3.3
