EZ-ACCESS PATHWAY - PATHWAY Ramp System Components; Key Ramp Components Identification

PATHWAY
®
Aluminum Wheelchair Ramp Kit Assembly Manual Page 6 of 40
1
2. BASIC SYSTEM COMPONENTS
Because of varying lengths/configurations, your system may not contain all of these basic system components.
Identify your system components before you begin assembly.
SURFACE OPTION
RAMP AND RAMP HANDRAIL OPTION
SOLID SURFACE
RAMP W/ TWO-LINE HANDRAIL
KEY RAMP COMPONENTS
PSLxxPR – SUPPORT LEG PAIRS
(xx DENOTES USABLE LENGTH)
PRGT – RAMP GROUND TRANSITION 18” X 36”
PRHBPR – RAMP HANDRAIL END BRACKET (PAIR)
PRRUC – UNIVERSAL CONNECTOR – RAMP TO RAMP
INCLUDES BASE FEET
INCLUDES
COMPONENTS TO
CONNECT RAMPS
AND RAMP
HANDRAILS
SHOWN ASSEMBLED
