PATHWAY
®
Aluminum Wheelchair Ramp Kit Assembly Manual
Page 7 of
40
1
KEY RAMP COMPONENTS, CONT’D.
RAMP HANGER PAIR
PRUT
–
RAMP UPPER TRANSITION
PRHRLU
–
UPPER HANDRAIL END LOOP
PRHRLL
–
LOWER HANDRAIL END LOO
P
PUAB
–
UNIVERSAL ANGLE BRACE
INCLUDES RAMP CORNER
PROTECTORS
6
8
Table of Contents
Table of Contents
4
Section 1: Configurations
5
Section 2: Basic System Components
6
Section 3: Platforms
8
Install Platforms
10
Install Support Tubes and Feet, then Adjust Platform Height
11
Connect Two Platforms Together
12
Install Universal Angle Brace - Platforms
14
Section 4: Ramps
15
Connect Ramp Sections
15
Install Ramps on Platforms
16
Attach Support Leg Brackets and Legs to Ramps
17
Install Universal Angle Brace - Ramps
19
Install Ramp Ground Transition
20
Install a Single Ramp Run to an Existing Structure
22
Anchor Ramp Upper Transition
23
Angle Ramps with Respect to Platforms, Porches, or Decks
23
Bridge Plate
24
Section 5: Handrails
25
Ramp Handrails
25
Assemble Platform Handrails
26
Install Platform Handrails
27
Section 6: Closures
28
Closure - Upper Rail and Curb
28
Closure - Lower Rail
32
U-Shaped Closure
33
Section 7: Final Platform/Ramp Steps and Checks
34
Secure Ramps to Platforms
34
Install Ramp Handrail End Loops
35
Install Ramp Corner Protectors
36
Touch-Up Architecturally Finished Handrails
36
Final Checks
36
Section 8: Optional Equipment
37
Landing Pad
37
Ramp Lower Transition
38
Section 9: Maintenance and Safety
39
Periodic Maintenance and Safety
39
Section 10: Deicing
39
