EZ3-TouchPLC
Modular
3 Specification
EZ3TouchPLC Modular with DH+ option
Part Number
EZ3-T6C-EH-PLC-E
EZ3-T7C-E-PLC-E
EZ3-T8C-E-PLC-E
EZ3-T10C-E-PLC-E
EZ3-T15C-E-PLC-E
EZ3-T8C-EH-PLC-E
EZ3-T10C-EH-PLC-E
EZ3-T15C-EH-PLC-E
EZW-T10C-E-PLC-E
EZW-T15C-E-PLC-E
EZW-T10C-EH-PLC-E
EZW-T15C-EH-PLC-E
I/O Base
4 Slot PLC Base
8 Slot PLC Base
Display Type
5.7” TFT (65K Colors)
7” TFT (65K Colors)
8” TFT (65K Colors)
10.4” TFT (65K Colors)
15” TFT (65K Colors)
Brightness/Life
400 nits / 75,000 hours@55 ° C
Screen Resolution
320 x 240
800 x 480
800 x 600
1024 x 768
Touch Screen
5-wire Analog Resistive Touch Screen
Num of Display Screens
Up to 999 Limited by display memory
Display Screen Saver
Yes, Backlight Off
HMI User Memory
4MB Built-in Flash Memory (Note Due to how HMI memory is consumed in the EZTouch Hardware this is sufficient for 99% of applications)
16 GB SSD
Maximum I/O Capacity
32 I/O Max (soon to become 64) (Expandable up to 2048 I/O)
64 I/O Max (soon to become 128) (Expandable up to 2048 I/O)
Maximum
25 Watts @ 24VDC
40 Watts Max
Power Consumption
Processors
Two 32 Bit, 40 MHz RISC Processors (One for PLC and One for HMI)
HMI - Intel Atom E640 1 G Hz
Total PLC Memory
64 KB (Ladder)
# of PLC Registers
8192 16Bit, 8192 Variables
PLC Typical Scan Time
3ms (1K Boolean)
Real Time Clock/Cal.
Built-in
Battery Backup
Yes
PLC LED Indicators
Input Power, CPU Status (Run, Program & Run/Program), Low Battery, Program PLC and Run Mode LED indicators
I/O Supported
EZIO Screw-down modules with status LEDs and Removable Terminal Block; DC / AC / Analog / Relay / Thermocouple / High Speed Counter, PWM, RTD, 31 different mix-n-match
Cube plug-in I/O modules with LED Indicator for each I/O point & removable plug-in terminal block. 4 Relay Out 2 Amp 1 Form A also available.
Electrical Noise
Nema ICS 2-230 Showering arc; ANSI C37.90a SWC; Level C Chattering Relay Test
Withstand Voltage
1000VDC (1 minute between power supply input terminal and protective ground)
Insulation Resistance
Over 20M Ohm between power supply input and terminal and protective ground
Enclosure
Nema 4, 4x (indoor)
Operating Temperature
0 to 55°C (32 to 131°F)
Storage Temperature
-25 to 65°C (-13 to 149°F)
Vibration
5 to 55Hz 2G’s for 2 hours in X,Y,and Z axis
Shock
10G for under 12ms in the X,Y, and Z axis
Humidity
10-95% Non-Condensing
USB & microSD ports
1 USB port for programming, 1 USB port for Datalogging and 1 microSD slot for additional data storage
Communication Ports
Built-in USB, RS232 and Ethernet Ports
Agency Approval
UL, CUL, CE
External Dimensions
8.048” x 6.146” x 4.325”
10.894” x 8.748” x 4.363”
13.584”x10.594”x 4.299”
13.00”x16.75”x6.25”
(204.41 x 156.11 x 109.87mm)
(276.71 x 222.20 x 110.82mm)
(345x269.1x109.20mm)
(330.2 x 425.25 x 158.7mm)
Weight
3 lbs
5 lbs
7 lbs
12 lbs
