TRT800H / P/N 800ATC-H-(2xx)-(2xx)
Operation and Installation
39
Document-No: 03.2124.010.71e / Revision: 2.10
Step
Display (Example)
7. At this stage the respective speed
category shall be selected by using
the rotary knob.
MODE
8. At this stage a GPS receiver for
ADS-B Out can be selected
(Selectable by rotary knob).
MODE
9. At this stage remote interface for
communication between TRT800H
and remote header can be activated
(Selectable by rotary knob).
Remote interface must only be
activated if a remote header is
connected
MODE
10. With ID further Records can now
be created and configured as
described in the aforementioned
steps
At start-up of the transponder one of
the defined records with all
associated configurations need to be
selected
MODE
Records
ID=Edit Records
EXIT
Record 1:
REMOTE Header: Yes/No
next
Record 1:
GPS/INT/EXT: NMEA/..
next
Record 1:
Speed Cat.: 08-15
next
