ENGLISH
Checkiftheparachutecablesarepresent,and,ifnecessary,
securethemonthetwoendsofthesupportprofile,housingthe
biggerendofthecableintheseats(Fig.38ref.a).
Check if the three anti-vibrationspacers (Fig. 38 ref. b)  are
present,and,ifnecessary,insertthemontheouteredgeofthe
supportprofile,positioningthemattheendsandcentrally(for
profilesofover3meters).
11A INSTALLING THE PARACHUTE AND THE SPACERS
12A FITTING THE SIDE PANELS A140 AIR H100-H140
Fitthesidepanelsasshowninfig.40ref.1
SidepanelforA140AIRH100
Thefigureshowstheinstallationoftherightsidepanel,proceedinthesamewayfortheleftpanel.
Fitthesidepanelsasshowninfig.40ref.2
SidepanelforA140AIRH140
Thefigureshowstheinstallationoftherightsidepanel,proceedinthesamewayfortheleftpanel.
Tofitthesideelements,prepare7platesonthesupportprofile
tomountthesideelementsandthecentralbracket(forprofiles
over3m)(fig.39).
Ifyoudonotwanttofitthesideelements,fit3bracketstosecure
thehousing,twosidebracketsandacentralbracket(forprofiles
over3m),placingonlyonesideplateinsteadof3asshownin
fig.39ref.a.
fig. 38
fig. 40
fig. 39
