ENGLISH
Ifyoudonotwanttoinstallsidepanels,youneedtofit3housing
fixingbrackets,twolateralandonecentral(forprofileslongerthan
3m),asshowninfig.42ref.5.
SecurethesidepanelsH100andH140usingthe3supplied
screwsasshowninfig.41ref.3andref.4.
Version A140 AIR H140 is supplied with higher fixing brackets
H140.
AssemblyoccursasforversionA140AIRH100.
fig. 42
fig. 41
