13A INSTALLING THE CLOSING HOUSING
• Laytheclosinghousingonthespacersyouhadpreviously
mounted,asshowninFig.43a or b.
• Tokeepthehousingopen,liftit(Fig.43ref.c)andpushit
(Fig.43ref.d)towardtheprofileuntilthemetalprotrusionfits
intheprofileseat.
• Securetheparachutecablesintheappropriateseats(Fig.43
ref.e)
•
Theclosinghousingislockedinlinewiththetwosidepanels
andthecentralplateorthefixingbrackets(Fig.43ref.f)
• Theclosinghousingispre-markedtoadaptittodifferentleaf
thickness values. Eliminate excess profile by cutting at the
pointsindicatedinfig.43ref.g.
If you are using the internal release, in order to close
the housing correctly, drill a hole near the release
knob.
fig. 43
We recommend you to use the central plate only
with VP (passage width ) from 1500mm or higher.
