44
ENGLISH
LOW ENERGY
Values higher than those indicated in the table are obtained by interpolation as indicated by the EN16005 standard.
Table 2 below indicates the minimum stroke time per leaf referred to door mass and leaf stroke as per standard EN16005 :
The EN16005 standard in force in European Community countries provides for the use of monitored devices or machine opera-
tion in LOW ENERGY mode.
The LOW ENERGY mode provides for a limitation of the maximum kinetic energy of the leaf and forces.
Table 1 provides an indication of the maximum speed settable on the electronic board based on the mass of the leaf.
In any case it is necessary to verify that the set speed value ensures compliance with EN16005.
For more details, please refer to standard EN16005.
Table 1 below shows the mass of the leaf and the speed to be set with reference to the mass.
The setting of the maximum force on opening and closing on the board must not be higher than 5.
WARNING:
Operation at low energy must not be used when a large proportion of users are elderly, infirm, disabled or children. In this
case contact of the door with the user is UNACCEPTABLE:
In these cases special monitored sensors must be used or suitable mechanical protection devices or sensors
(for opening only)
TAB.1
TAB.2
Mass(Kg] Setting Speed
10 9
20
8
30 7
40 6
50
6
60 5
70 5
80 5
90 4
100 4
110 4
120 4
130 4
140 4
150 4
160 3
170 3
180 3
190 3
200 3
210 3
220 3
230 3
240 3
A100 Compact
A140 AIR
90% of
the stroke
leafD
[m]
LeafMass
10 20
30 40 50 60 70 80 90 100 110 120 130 140 150
Minimum
timestrok
e
0,7
1,3 1,8 2,1 2,5 2,7 3,0 3,2 3,5 3,7 3,9 4,0 4,2 4,4 4,6 4,7
0,8
1,4 2,0 2,4 2,8 3,1 3,4 3,7 3,9 4,2 4,4 4,6 4,8 5,0 5,2 5,4
0,9
1,6 2,2 2,7 3,1 3,5 3,8 4,1 4,4 4,7 4,9 5,2 5,4 5,6 5,8 6,0
1,0
1,8 2,5 3,0 3,5 3,9 4,3 4,6 4,9 5,2 5,5 5,8 6,0 6,3 6,5 6,7
1,1
1,9 2,7 3,3 3,8 4,3 4,7 5,1 5,4 5,7 6,0 6,3 6,6 6,9 7,1 7,4
1,2
2,1 3,0 3,6 4,2 4,7 5,1 5,5 5,9 6,2 6,6 6,9 7,2 7,5 7,8 8,0
1,3
2,3 3,2 3,9 4,5 5 5,5 6,0 6,4 6,8 7,1 7,5 7,8 8,1 8,4 8,7
1,4
2,5 3,5 4,2 4,9 5,4 5,9 6,4 6,9 7,3 7,7 8,0 8,4 8,7 9,1 9,4
1,5
2,6 3,7 4,5 5,2 5,8 6,4 6,9 7,3 7,8 8,2 8,6 9,0 9,4 9,7 10
