Facility Explorer FX15 - FX15 Extended Range Controller Specifications

FX15 Controller Technical Bulletin
57
Single cable lengths (Cont.)
Digital Inputs DI1 - DI8
Analog Inputs AI1 - AI6
Triac outputs (when present)
Analog Outputs AO1 - AO4
Remote Display
Extension Modules
Display and Extensions cable type
Maximum 100 m (328.1 ft) with diameters ≥ 0.6 mm (0.02
in.)
Maximum 100 m (328.1 ft) with diameters ≥ 0.6 mm (0.02
in.)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 100 m (328.1 ft) where A ≥ 1.5 mm
2
(0.002 in.
2
)
Maximum 3 m (9.8 ft) if display is powered by controller.
Maximum 1km (1.9 mi) if display independently powered
Maximum 1km (0.6 mi)
Belden 4-core, twisted pair, shielded
Compliance
Europe
CE Mark – Johnson Controls, Inc.,
declares that the FX15 Controllers are in
compliance with the essential
requirements and other relevant
provisions of the
EMC Directive 2004/108/EC and the
Low Voltage Directive 2006/95/EC.
Canada
– UL Listed (PAZX7), CAN/CSA C22.2
No. 205, Signal Equipment.
UL Recognized (XAPX8), CAN/CSA
C22.2 No. 24, Temperature Indicating and
Regulating Equipment. Industry Canada,
ICES-003.
United States
– UL Listed (PAZX), UL 916, Energy
Management Equipment. UL Recognized
(XAPX2), UL 873, Temperature Indicating
and Regulating Equipment. FCC
compliant to CFR 47, Part 15, Subpart B,
Class A.
FX15 Extended Range Controller
Table 26: FX15 Extended Range Controller
Product
FX15 extended range controller
Power Supply Requirements
24 VAC ±15%, 50/60 Hz - Class 2 Power Supply
Power Consumption
15 VA at maximum load
Protection Class
IP20 controller
IP40 integrated MUI
Isolation
See Isolation Diagram.
Ambient Operating Conditions
-40 to 60°C (-40 to 140°F), 10 to 95% RH (noncondensing)
Ambient Storage Conditions
-20 to +70°C (-4 to 158°F), 10 to 95% RH (noncondensing)
Dimensions (H x W x D)
142 mm (5.6 in.) x 215 mm (8.5 in.) x 49 mm (1.9 in.)
Weight (with package)
0.74 Kg (1.6 lb)
I/O ratings
See I/O Technical Details.
Connection terminals for signals and
power supply
Screw terminals for a maximum 1 x 1.5 mm
2
(0.002 in
2
) wires,
included in the package.
Continued on next page…
