60 Fadal/Sinumerik 810D CNC: Definition of Offsets October 2000
SIEMENS CONTROL
Operator Manual
Fadal
Power Off
The Siemens Control is equipped with a battery-backed memory board
and can be turned off at any time without loss of memory.
The “POWER ON” procedure requires aligning the axis markers before the
referencing procedure is used. Alignment can be accomplished by jogging
the axes until the markers are in line.
However these markers can be aligned before the power is switched off,
making the “POWER ON” procedure much quicker.
Power Off Procedure:
1) From the MDA mode, type SETCS.
2) Press the CYCLE START hard key.
3) Leave the machine at this display.
4) Press the E-stop button.
5) To power off the machine, turn the power switch counter
clockwise.
