46 Fadal/Sinumerik 810D CNC: Definition of Offsets October 2000
SIEMENS CONTROL
Operator Manual
Fadal
Using the TOOL Soft Key to set the Tool Offsets
1) The TOOL soft key is accessed from the main manual display. To get to
the main manual display press the OFFSETS PARAM hard key.
2) Press the Tool List soft key. The Tool List table is displayed.
3) Use the cursor key pad arrows to move to the desired fields in the table
for editing.
(continued on next page)
