7.
CABLES
RS-232 serial line
262
DDS
HARDWARE
Ref.1310
PC-VT connection using an RS-232 cable (with adapter)
The adapter RS232/RS422 BE has the following connectors at its ends:
The connection cable when using the adapter RS232/RS422 BE will have
the following connectors at its ends:
The connection is:
F. H7/13
RS-232 serial line connection between a PC and VT from ESA (with
adapter).
F. H7/14
RS232/RS422 BE adapter.
F. H7/15
A.
Connector of the RS-232 cable for direct connection to the PC.
C. Connector of the RS-232 cable to connect to the B port of the adapter.
F. H7/16
RS-232 connection between PC and VT with adapter.
9-pin Sub-D,
type female
connector
RS-232 cable
RS422/RS232 BE
adapter cable
9-pin Sub-D,
type female
connector
to the VT panel
(ESA)
Connect this end
of the adapter
directly to the
MSP connector
of the VT
B port of the adapter
(Sub-D, M9)
Connect the end of the RS-
232 or RS-422 cable to this
end of the adapter.
RS422/RS232 BE
Adapter
A port of the adapter
(Sub-D, M25)
6
9
1
5
1
13
25
14
5
1
6
9
5
1
6
9
RS-232 cable
A
C
to the B port of the
adapter (Sub-D, F9)
to PC
(Sub-D, F9)
These two connectors are located at both ends of the RS-232 cable when
connecting with the adapter.
8
6
4
2
3
5
Pin
3
2
5
Pin
CTS
DSR
DTR
RxD
TxD
RTS
Signal
CHASSIS
RxD
TxD
GND
Signal
7
Maximum length: 15 meters
To PC
To the B port
of the adapter
Sub-D, F9
Sub-D, F9
AC
