Fagor DDS User Manual

Installation
INSTALLATION
Location
8.
269
DDS
HARDWARE
Ref.1310
Auxiliary modules Dissipated power
APS-24 60 W
CM 1.60 0 W
ER+TH-x/x and
ER+TH-18/x+FAN
It depends on the activation fre-
quency of the Ballast protection
circuit.
MAINS FILTER 42A 19 W
MAINS FILTER 130A 40 W
MAINS FILTER 180A 61 W
Modular drives Power dissipated at 4/8 kHz
AXD/MMC 1.08 33/44 W
AXD/MMC 1.15 69/89 W
AXD/MMC 1.25 88/132 W
AXD/MMC 1.35 156/195 W
AXD/MMC 2.50 225/305 W
AXD/MMC 2.75 270/389 W
AXD/MMC 3.100 351/510 W
AXD/MMC 3.150 536/605 W
MMC 3.200 834/840 W
SPD 1.15 98/98 W
SPD 1.25 110/130 W
SPD 1.35 195/201 W
SPD 2.50 349/350 W
SPD 2.75 289/333 W
SPD 2.85 432/438 W
SPD 3100 496/546 W
SPD 3150 626/668 W
SPD 3200 1163/1187 W
SPD 3250 1333/1344 W
Compact drives Power dissipated at 4/8 kHz
ACD/CMC 1.08 40/50 W
ACD/CMC 1.15 87/118 W
ACD/CMC 1.25 110/139 W
ACD/CMC 2.35 160/206 W
ACD/CMC 2.50 220/295 W
SCD 1.15 123/123 W
SCD 1.25 150/150 W
SCD 2.35 215/220 W
SCD 2.50 275/315 W
SCD 2.75 289/333 W
