Compatibility
COMPATIBILITY
VECON-3 board
13.
381
DDS
HARDWARE
Ref.1310
13.6 VECON-3 board
This board replaces the VECON-2 board.
13.7 VECON-4 board
This board replaces the VECON-3 board.
13.8 Boot for VECON-2
The boot of version v.06.02 and later of the WinDDSSetup allow loading
the software versions on VECON-2
boards (version VEC2 02A).
13.9 Boot for VECON-3
The boot of version 06.18 and older of the WinDDSSetup allow loading
the software versions on VECON-3
boards (version VEC3 01A).
13.10 Boot for VECON-4
The boot of versions 06.26 and 08.05 and older of the WinDDSSetup al-
low loading the software versions on VECON-4 boards (versión VEC4
01A).
13.11 SERCOS card (16 MBd)
This card will not be compatible with software versions older than 06.05.
With software versions 06.05 and later, this new board may be used to ex-
change data between the CNC and the drives that make up the SERCOS
ring at 2, 4, 8 and 16 MBd.
Version of the VECON-3 board Software version
VEC 01A and later 06.18 and later
NOTE. It is possible but not recommended to have the same machine
with several units where one controls its motor with a 04.xx version and
hardware with VECON another one that controls its motor with a 05.xx
version and hardware with VECON-2 and a third one that controls its mo-
tor with 06.18 version or later and VECON-3 hardware.
Versión of the VECON-4 board Software version
VEC 01A and later 06.26 and later
08.05 and later
NOTE. It is possible but not recommended to have the same machine
with several units where one controls its motor with a 05.xx version and
hardware with VECON-2 another one that controls its motor with a
06.18 version and hardware VECON-3 and a third one that controls its
motor with 08.05 version and hardware VECON-4 hardware.
NOTE. The boot of previous WinDDSSetup versions is incompatible with
board versions VEC2 02A.
NOTE. The boot of previous WinDDSSetup versions is incompatible with
board versions VEC3 01A.
NOTE. The boot of previous WinDDSSetup versions is incompatible with
board versions VEC4 01A.
NOTE. Therefore, in order to select a baudrate higher than 4 Mbaud, the
drive must have this SERCOS board and software version v.06.05 or new-
er.
INFORMATION. Drives having this board or older ones may be added to
the SERCOS ring. However, all the drives must set with the same trans-
mission speed.
