Compatibility
COMPATIBILITY
CAPMOTOR-2 board and type of feedback
13.
383
DDS
HARDWARE
Ref.1310
13.15 CAPMOTOR-2 board and type of feedback
13.16 Recognizing RPS power supplies
From drive software version 06.09 on, it recognizes the identifier of RPS
regenerative regulated power supplies and their parameters may be set.
13.17 APS-24 auxiliary power supply with PS, XPS or RPS
13.18 Power supplies compatible with FM9 motors
Feedback device type Motor feedback board
Resolver CAPMOTOR-1
Stegmann
TM
encóder CAPMOTOR-1, CAPMOTOR-2
Encoder with square signals U, V and W CAPMOTOR-1, CAPMOTOR-2
Encoder with C and D signals CAPMOTOR-1, CAPMOTOR-2
EnDat with incremental A and B signals CAPMOTOR-2
SSI CAPMOTOR-2
INFORMATION. Remember that the CAPMOTOR-1 board has been dis-
continued.
NOTE. WinDDSSetup versions older than 06.09 are incompatible with
RPS
power supplies.
APS-24 XPS or RPS power supplies
Ref. PF 23A or older Incompatible
Newer than Ref. PF 23A Compatible
APS-24 PS power supplies
All PF references Compatible
Motor
references
PS power
supply
XPS power
supply
RPS power
supply
FM9-B055-C5C-E01-A Incompatible Incompatible RPS-75
FM9-B071-C5C
-E01 Incompatible Incompatible RPS-80
