Power supplies
POWER SUPPLIES
Regenerative regulated power supplies
2.
89
DDS
HARDWARE
Ref.1310
The next table shows the signals and other considerations related to each
pin of connector X6:
T. H2/37 Description of the pins of connector X6.
1 ERROR RESET
System error RESET input
(24 V DC; 4.5-7 mA).
2 N.C. Not connected
3 GND
0 volts reference for digital inputs.
Error RESET (1) and System Speed Enable (5).
4 PWM ENABLE
Safety.
Power bus voltage enable input (24 V DC).
5
SYSTEM SPEED
ENABLE
General system speed enable.
(24 V DC; 4.5-7 mA).
6 SYSTEM OK
Contact indicating module status. It opens in case
of failure. Limit 1 A at 24 V.
7 SYSTEM OK
