49
Presetting servos
ANLAGENBAU
EN
CV Description Range Default
setting
153 Hold position “green” Address 1 0-127 95
154 Positioning time 0-255 40
155 Rocking amplitude Hold position “red”
Address 1
0-127 0
156 Rocking time Hold position “red” Address 1 0-255 0
157 Rocking amplitude Hold position “green”
Address 1
0-127 0
158 Rocking time Hold position “green”
Address 1
0-255 0
190 HighByte Address 2 0-8 0
191 LowByte Address 2 0-255 0
192 Hold position “red” Address 2 0-127 0
193 Hold position “green” Address 2 0-127 0
Tab. 1: Synopsis of all configuration variables (CV).
* ADVICE: If you use a Motorola digital control unit, default settings for the
addresses of configuration variables 121, 131, 141 and 151 are not available.
