2.2. Indicator signs
Name
Meaning
Description
POWER Power LED Always light, has power, you
can start using the A1 single
port gateway.
REG Registration
status
indicator
Registered, the lights lit, the
registration fails, the light
flashes; do not use Notes
Books, lights out.
PHONE Phone work
status lights
Show VoIP service is being
used, or PSTN services,
service, hang up: Death; pick
up after the state if it is VoIP,
Always; if you are in PSTN
state: off.
WAN WAN network
interface lights
Indicator light, WAN port
connected to the network.
Flashing: Data transfer.
LAN LAN network
interface lights
Indicator light, LAN port
connected to the network.
Flashing: Data transfer.
2.3. Connector description
Name Meaning Description
POWER Power switch
Output:12VDC，500mA。
LINE Lifeline PSTN access lines.
PHONE FXS Interface Ordinary telephone connection, or
switch into the line.
LAN Network
Interface
10/100M Adaptive connected PC.
WAN Network
Interface
10/100M Adaptive connected to
the RJ45 port of Internet。
