5.3.2.2. LAN Config
LAN Config
Field name explanation
LAN IP Specify LAN static IP.
Netmask Specify LAN Netmask.
DHCP Service
Select the DHCP server of LAN port or not. After you
modify the LAN IP address, gateway will amend and
adjust the DHCP Lease Table and save the result
amended automatically according to the IP address and
Netmask. You need restart the gateway and the DHCP
server setting will take effect.
NAT Select NAT or not.
Bridge Mode
Select Bridge Mode or not: If you select Bridge Mode,
the gateway will no longer set IP address for LAN
physical port，LAN and WAN will join in the same
network. Click “Apply”, the gateway will reboot.
Notice: If you choose the bridge mode, the LAN configuration will be
disabled.
5.3.2.3. Qos Config
The gateway support 802.1Q/P protocol and DiffServ configuration. VLAN
functionality can use different VLAN IDs by setting signal/voice VLAN and data
VLAN. The VLAN application of this device is very flexible.
