MPC-6000 / MPC-7000 / RND-2 INSTALLATION, OPERATION AND MAINTENANCE MANUAL
21
MPC-REL (Optional Releasing Module for MPC-6000 only)
Two power limited releasing circuits
Four non-power limited open collector circuits
Releasing Circuits are rated at 1.5A at 24VDC, filtered
Open Collector Circuits are rated at 200mA at 24VDC, filtered
Maximum cumulative current output must not exceed 3A
Each Releasing Circuit requires REL-EOL module (P/N 500-696359) installed as close as
possible to the last solenoid for proper wire supervision
Requires an RPT-1 transformer
REL-EOL module (P/N 500-696359) is required for supervision of open and short circuits on
the releasing circuit. REL-EOL must be in the same enclosure or close nippled to the last
solenoid in the loop.
