Auxiliary Module Battery Calculations
Panel and Module Current Standby Current (A) Alarm Current (A)
RDC-2 Remote Standby 0.048 X = + NA
Annunciator Alarm 0.085 X = NA +
RDC-3 Remote Standby 0.025 X = + NA
Annunciator Alarm 0.048 X = NA +
SRU-2 Serial Standby 0.032 X = + NA
Relay Unit Alarm 0.192 X = NA +
SRE-8 Serial Standby 0.000 X = + NA
Relay Extender Alarm 0.170 X = NA +
SLU-2 Serial Standby 0.018 X = +
Annunciator Unit Alarm (Note 5) 0.042 X = NA +
SLE-16 Serial Standby 0.005 X = +
Annunciator
Extender
Alarm (Note 5) 0.032 X = NA +
Total Auxiliary
Module Current
Place these totals in the Total System Current table
Go to Device Current Calculations
Device Current Calculations
Device Current
Catalog # Quantity X Current (A) Standby Current (A) Alarm Current (A)
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
4-wire Smoke Detectors
Catalog # Quantity X Current (A)
Standby X = + NA
Alarm X = NA +
Standby X = + NA
Alarm X = NA +
End of Line Relay
Catalog # Quantity X Current (A)
X = + +
Notification Appliances
Catalog # Quantity X Current (A)
X = NA +
X = NA +
X = NA +
X = NA +
Other = + +
TOTAL DEVICE Current
Place these totals in the Total System Current table
Go to Total System Current Calculations
