Faraone ZP8 - Model Zp 8 General Technical Data

USE AND MAINTENANCE MANUAL - SECTION 2
AERIAL PLATFORM ZP – Rev. 05_2018
Page 2-4
The general technical features of the model ZP Elevating Platform in the
different possible configurations are as follows:
Table NOTE:
* : Maximum pressure per outrigger considering that the weight of the platform plus the
maximum load on the basket are wholly distributed on one side only of the platform (wholly
asymmetrical load)
MODEL ZP 8 GENERAL
TECHNICAL DATA
150
200
□
Internal
Use
□
Outdoor
Use
□
Internal
Use
□
Outdoor
Use
Weight of the machine: (Total)
383 kg
395 kg
402 kg
414 kg
Stabiliser weight:
12 kg
15 kg
15 kg
18 kg
Machine height: (in transport
position)
195 cm
Maximum resting pressure on
the ground: per wheel/stabiliser
(*)
185 daN
190 daN
210 daN
215 daN
Maximum gradeability: (in
transport position)
15% - 9°
Maximum longitudinal work
slope:
Base “LEVEL”
Maximum transversal work
slope:
Base “LEVEL”
Machine base with stabilisers:
(length x width)
136x136
cm
210x210
cm
210x210
cm
255x255
cm
Machine base without
stabilisers: (length x width)
136.5 cm x 80 cm
Manual maximum horizontal
side force:
200 N
400 N
Maximum hydraulic system
pressure:
90 bar
90 bar
Capacity of the hydraulic tank:
~ 9 Litres
Power supply
• Standard
• Optional
220/230 V 50/60 Hz
2 Batteries AGM 12V 85 Ah
