Faraone ZP8 - ATTACHMENT 1 - Layout for Decal Application

USE AND MAINTENANCE MANUAL - SECTION 9
AERIAL PLATFORM ZP – Rev. 05_2018
Page 9-2
ATTACHMENT 1 – Layout for decal application
Pos.
SYMBOL
DESCRIPTION
Pos.
SYMBOL
DESCRIPTION
1
DANGER SIGN
CRUSHING AND
TRAPPING THE
LOWER LIMBS
2
150 kg
INDICATION
Maximum number of
persons and load on
the cage
3
200 kg
INDICATION
Maximum number of
persons and load on
the cage
4
INDICATION
“INSTRUCTIONS FOR
CORRECT INSERTION
OF THE STABILISERS'
FEET”
5
PROHIBITION SIGN
UNAUTHORISED
PERSONNEL MUST
NOT USE THE
MACHINERY
6
OBLIGATION SIGN
REFER TO THE
OPERATING MANUAL
7
OBLIGATION SIGN
WEAR NON-SLIP
SHOES
8
PROHIBITION SIGN
DO NOT REMOVE THE
SAFETY GUARDS AND
DEVICES
9
INDICATION
"EMERGENCY
DESCENT"
10
INDICATION
“EMERGENCY
DESCENT
PROCEDURE”
11
PLATE
"MAIN TECHNICAL
FEATURES OF THE
MACHINE"
12
INDICATION
“HOLDING ONLY
1 PERSON”
13
INDICATION
“INTERNAL USE AND
IN THE ABSENCE OF
WIND”
OR
“OUTDOOR USE”
