Faraone ZP8 - Model Zp 10 General Technical Data

USE AND MAINTENANCE MANUAL - SECTION 2
AERIAL PLATFORM ZP – Rev. 05_2018
Page 2-5
Operators inside the work
platform:
1
2
Maximum capacity in the work
platform:
150 kg
200 kg
Maximum operating height:
(from the ground to the floor of the
work platform)
• STANDARD position
• HIGH position
5.06 m
6.04 m
Internal dimensions of the work
platform:
~ 61 cm x 61 cm
~ 61 cm x 100 cm
MODEL ZP 10 GENERAL
TECHNICAL DATA
150
200
□
Internal
Use
□
Outdoor
Use
□
Internal
Use
□
Outdoor
Use
Weight of the machine: (Total)
498 kg
522 kg
517 kg
541 kg
Stabiliser weight:
12 kg
18 kg
15 kg
21 kg
Machine height: (in transport
position)
195 cm
Maximum resting pressure on
the ground: per wheel/stabiliser
(*)
230 daN
235 daN
250 daN
260 daN
Maximum gradeability: (in
transport position)
15% - 9°
Maximum longitudinal work
slope:
Base “LEVEL”
Maximum transversal work
slope:
Base “LEVEL”
Machine base with stabilisers:
(length x width)
136x136
cm
255x255
cm
210x210
cm
300x300
cm
Machine base without
stabilisers: (length x width)
136.5 cm x 80 cm
Manual maximum horizontal
side force:
200 N
400 N
Maximum hydraulic system
pressure:
110 bar
110 bar
Capacity of the hydraulic tank:
~ 9 Litres
