Faraone ZP8 - Model Zp 16 General Technical Data

USE AND MAINTENANCE MANUAL - SECTION 2
AERIAL PLATFORM ZP – Rev. 05_2018
Page 2-8
Manual maximum horizontal
side force:
200 N
400 N
Maximum hydraulic system
pressure:
115 bar
115 bar
Capacity of the hydraulic tank:
~ 9 Litres
Power supply
• Standard
• Optional
220/230 V 50/60 Hz
2 Batteries AGM 12V 85 Ah
Operators inside the work
platform:
1
2
Maximum capacity in the work
platform:
150 kg
200 kg
Maximum operating height:
(from the ground to the floor of the
work platform)
12.00 m
Internal dimensions of the work
platform:
~ 61 cm x 61 cm
~ 61 cm x 100 cm
MODEL ZP 16 GENERAL
TECHNICAL DATA
150
□
Internal Use
□
Outdoor Use
Weight of the machine: (Total)
624 kg
692 kg
Stabiliser weight:
21 kg
38 kg
Machine height: (in transport
position)
296 cm
Maximum resting pressure on the
ground: per wheel/stabiliser (*)
270 daN
295 daN
Maximum gradeability: (in transport
position)
15% - 9°
Maximum longitudinal work slope:
Base “LEVEL”
Maximum transversal work slope:
Base “LEVEL”
Machine base with stabilisers:
(length x width)
300x300 cm
500x500 cm
Machine base without stabilisers:
(length x width)
136.5 cm x 80 cm
Manual maximum horizontal side
force:
200 N
