1. Emergency stop/switch-off button
2. Ascent/descent control button
3. LED power indicator
4. 220/230 V main power supply switch
5. Closable access door with lock
6. Main switch 24 V power supply
General information
Before operating the machine from the ground control desk, the following
conditions of the controls must be met:
• Ground control station – The main power supply switch must be
switched on.
• Ground control station - The Emergency stop/switch-off button must
be in RESET position (POWER SUPPLY CONNECTED).
• Work platform desk - The emergency stop/switch-off button must be
in RESET position (POWER SUPPLY CONNECTED).
Emergency stop/switch-off button
NOTE: in order for the machine to operate, the emergency stop/switch off
button on the machine must be in RESET position.
