Machine description – Instruments/Controls
02-17-2021 4812325897EN 29
#
Designation
Symbol
Function
10
Warning lights switch
(optional)
When pressed, the warning lights will be on.
11.
Direction indicators switch
(optional)
When pressed to one side, the respective indication
lights up. In the central position, the function is turned
off.
12.
Parking brake switch
Press the button to activate the parking brake; the
machine stops the engine running. Always use the
parking brake when the machine is on a sloping
surface.
13.
Control panel
Detailed information on how it operates is given
below.
