Machine description – Instruments/Controls
02-17-2021 4812325897EN 35
Functions description
#
Symbol
Designation and Function
1.
Warning lamp (Red)
Serious fault: Shut down the engine
immediately!
It turns on along with a message on the
screen.
2.
Warning lamp (Yellow)
Less serious fault: Correct as soon as
possible!
It turns on along with a message on the
screen.
3.
Heating (Yellow)
The symbol must be erased before moving
the ignition key to position 2 and activating
the starter motor.
4.
Park brake indicator (Red)
The lamp turns on when the parking brake
is activated.
5.
Fuel level (Yellow)
The symbol is turn on, there is less than
10% of the fuel left.
