Alternative 2
Short distance towing when the engine is inoperative
Chock the wheels to prevent the roller from
moving when the brakes are hydraulically
disengaged.
Press button (1) and move the hand pump (2) horizontally
until you feel resistance to movement, keep moving
several times until the brake is released.
Towing the roller
When towing/recovering, the roller must be
braked by the towing vehicle. A towing bar must
be used as the roller has no brakes.
The roller must be towed slowly, max. 3 km/h (2
mph) and only towed short distances, max. 300 m
(330 yards).
When towing/retrieving a machine, the towing
device must be connected to both lifting holes. The
pulling force must act longitudinally on the machine
as shown in the figure. Maximum gross pulling force
185 kN (41.590 lbf).
Reverse the towing preparations according to
alternative 1 or 2 in the preceding section.
