02-17-2021 4812325897EN 56
Transport
Before lifting or transport, lock the steering
joint. Follow the instructions in the respective
sections.
Apply the chocks to the cylinders (1) and then attach
them to the transport vehicle.
Place supports under the cylinder frame (2) to avoid
overloading the roller suspension when it is held by
tensioning cables.
Secure the machine with stretch handle (3) on all four
corners. The adhesives indicate the fixing points.
Remember to unlock the articulation before
starting the roller.
