Maintenance – Planned maintenance
01-06-2022 4812134740EN 106
Check the engine belt tension
Check positioning of the belt on the tensioner, which should be
centred, and if the belt shows signs of too much wear, it should
be replaced.
Check the engine manual for more information.
Steering hitch – Tightening
The easiest way to identify if you have this type of
steering hitch is that it has a new type of nut (1) at
the top as shown.
Actual torque (Nm) should be when the machines
M16
270 Nm
Drum cartridge - Cleaning the ventilation screw
Clean the drum's ventilation hole and ventilation screw
(1). The hole is required to eliminate excess pressure
inside the drum.
Fig. Motor:
1. Belt;
2. Tensioner
