Technical specifications – General
01-06-2022 4812134740EN 28
Technical specifications – General
Cummins F 3.8
Turbo diesel
engine,
water-cooled
Engine speed, loading/unloading
Engine speed, working/transport
See section “Electrical system” – fuses
110 kPa (1.1 kp/cm
2
) (16psi)
The tires filled with fluid (up to 395 kg/tire).
When doing tire maintenance, pay attention
to their condition.
Tire Water Blasting procedure
Jack the Roller and turn the tire to bring the valve
to the top position.
Remove the valve core housing and make
connection with tire blasting pump and fill the
water with Cacl2 solution 395 lits per tire.
Set the final working press (110kpa-16psi) after
unjack the roller in valve position in bottom side.
Tyre blasting must in bead seating with
control pressure & valve position in up
position.
