01-06-2022 4812134740EN 46
Transport with machine speed (Applicable to
DCM)
User can see the machine speed (12) in travel and working
mode. It’s applicable in DCM machine.
User settings
Users can change the lighting configurations (6), Brightness &
contrast. Machine speed (7) Applicable in Compaction meter.
SW: - 4812133751– Display
4812133750– ECU software
Vibration status
Vibration status activated on the drum (8).
Automatic Vibration Control – AVC
Press bottom buttons (9) on the far edge of the Display. An arrow
will appear on the right (10).
Press the bottom button (9) and the submenu is displayed.
Press the bottom button (9) to activate AVC (11), and after it is
activated, the icon will appear on the bottom right of the display.
To activate the vibration, click on the button (3).
