Operation - Vibration
01-06-2022 4812134740EN 64
Operation – Vibration
Vibration switch
To activate or deactivate the vibration, activate the high or
low amplitude selector (8).
The operator should activate it using the vibration switch,
located under the forward/reverse lever (5).
Vibration – Activation
Never activate vibration when the machine is
stationary. This can damage both the surface
and the machine.
Engage and disengage vibration using the switch (3) on
the underside of the forward/reverse lever (5).
The vibration should be activated only at high or low speed.
Always switch off vibration before the machine comes to a
standstill.
Fig. Control panel:
8. Amplitude switch.
8
Fig. Forward/reverse lever;
3. Vibration switch.
5. Forward/reverse lever.
3
5
