01-06-2022 4812134740EN 113
Replacing the urea tank suction filter
The urea tank is located on the right side of the
machine.
Loosen and remove the tank multifunction unit (1),
then remove the suction filter (2) that is located in the
bottom of the unit.
Hand in the filter to an environment-friendly waste
disposal station.
Install the new suction filter (2) and refit the
multifunction unit (1) in the tank.
Replacing the urea pump filter
The urea pump is located on the right side of the
machine, beside the urea tank.
The filter is located at the bottom of the unit.
To access the filter, loosen the lid with a 27 mm sleeve
and remove the filter using the tool supplied with the
spare part filter.
Replace with new filter and reassemble the lid with
torque 20 Nm.
Hand in the filter to an environment-friendly waste
disposal station.
