D 11 9
Item Designation Brief description
15
Travel drive
preselector
For setting the maximum speed that can be reached when the
drive lever is at its stop.
A
The scale roughly matches the speed in m/min
(during paving).
m
The vehicle must not travel at max. transport speed
when the hopper is full!
f
The vehicle speed cannot be reduced to "0" with the
preselector. The vehicle advances slightly with deflect-
ed drive lever, even if the travel drive preselector is set
to zero!
16
Steering
potentiometer
The steering wheel movement is transferred electrohydraulically.
A
For precise adjustments (position "0" = straight-ahead),
see the straight-ahead travel synchronisation.
For turning on the spot, see switch
(turning on the spot).
17 Horn
Press in the case of emergencies and to indicate when the ve-
hicle starts to move!
A
The horn can also be used to communicate acoustical-
ly with the truck driver for material loading!
