4 Securing the load
4.1 Securing at the sides
m
Diagonal lashing secures the paver finisher at the sides
using the lashing points on the paver finisher and on the low-load trailer.
Fasten the lashing chains as shown.
4.2 Securing at the front
m
Diagonal lashing secures the paver finisher at the front using the lashing points on
the paver finisher and on the low-load trailer. Fasten the lashing chains as shown.
m
The lashing angles should be: "ß" between 6°-55° and "a" between 20°-65°!
