2 Menu structure
Menu of the "Home" displays
Displays:
- (1) Speed:
- Paving (tortoise)-(m/min) / (ft/min)
- Driving (hare) - (km/h) / (mph)
- (2) Fuel gauge
- (3) Level AdBlue
®
/ DEF tank (o)
m
If the level is too low, a warning also appears.
- (4) Paving material - conveyor level left / right
- (5) Paving material - auger level left / right
- (6) Actual temperature of the screen heater (°C) / (°F)
A
The display shows the average temperature of all screed sections.
A
Currently heated screed sections appear coloured in the corresponding graphic.
- (7) Extension distance - extendable part screed left (cm) / (inch) (o)
- (8) Extension distance - extendable part screed right (cm) / (inch) (o)
- (9) Course thickness - screed left (cm) / (inch) (o)
- (10) Course thickness - screed right (cm) / (inch) (o)
- (11) Crowning - (%) (o)
13
7
8
15
14
1
16
11
12
9
10
6
5
4
18
20
19
2
3
17
17
