Fayat Group Dynapac SD2500C - Screed set-up menu

D 22 33
"Screed" set-up menu
Menu for setting up the basic screed settings and screed functions.
- (1) Display and adjustment parame-
ters for the screed type
- Screed type 1, 2, 3, 4, 5
A
Please consult the screed type plate for
the parameter to be entered here, corre-
sponding to the last number of the
screed type.
A
If a different screed type has been con-
nected to the paver finisher, the corre-
sponding setting must be carried out!
- (2) Display and adjustment parameters for the screed heater
- (2.1): Electric heater
- (2.2): Gas heater
- (3) Display and adjustment parameters for "Delayed Screed Start" - delay time (sec)
A
On swivelling the drive lever, the floating function is only activated once an adjusted
time has elapsed.
A
Setting range 0-10 sec.
1
2
3
4
2.1
2.2
4.1 4.2 4.3
V5100TV / 3
