D 11 33
Item Designation Brief description
49
Left conveyor
"MANUAL"
Button with detent switch function and LED feedback:
- The function of the left conveyor is permanently
switched on at full conveying rate and is activated/de-
activated with the material limit switch in the material
tunnel.
- Switch OFF by pressing the button again.
A
To avoid excessive conveying, the system is shut off at
a defined material height!
- Pressing and holding the button can result in exces-
sive conveying.
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
50
Right conveyor
"MANUAL"
Button with detent switch function and LED feedback:
- The function of the right conveyor is permanently
switched on at full conveying rate and is activated/de-
activated with the material limit switch in the material
tunnel.
- Switch OFF by pressing the button again.
A
To avoid excessive conveying, the system is shut off at
a defined material height!
- Pressing and holding the button can result in exces-
sive conveying.
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
