D 11 39
Item Designation Brief description
55
Left auger
"MANUAL"
Button with detent switch function and LED feedback:
- The conveying function of the left half of the auger is
switched on continuously with full delivery capacity,
without material control via the limit switches.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
56
Right auger
"MANUAL"
Button with detent switch function and LED feedback:
- The conveying function of the right half of the auger is
switched on continuously with full delivery capacity,
without material control via the limit switches.
- Switch OFF by pressing the button again
A
The function is shut off by pressing the EMERGENCY
STOP button or restarting the vehicle.
A
The main function switch locks the conveying function.
f
On actuation, heed danger zones of moving parts of
the vehicle!
