Item Designation Brief description
63
Adjustment button:
Retract / lift
on left
Pushbutton function:
- To adjust the selected function in the
corresponding direction.
f
On actuation, heed danger zones of moving parts of
the vehicle!
64
Adjustment button:
Retract / lift
on right
Pushbutton function:
- To adjust the selected function in the
corresponding direction.
f
On actuation, heed danger zones of moving parts of
the vehicle!
65
Adjustment button:
Extend / lower
on left
Pushbutton function:
- To adjust the selected function in the
corresponding direction.
f
On actuation, heed danger zones of moving parts of
the vehicle!
66
Adjustment button:
Extend / lower
on right
Pushbutton function:
- To adjust the selected function in the
corresponding direction.
f
On actuation, heed danger zones of moving parts of
the vehicle!
