D 11 49
Item Designation Brief description
67
Fill vehicle for
paving process
Detent switch function and LED feedback:
- Filling function for the paving process.
The diesel engine's speed is increased to the preselected
nominal speed and all conveying functions set to "Auto-
matic" (conveyor and auger) are engaged.
A
The main function switch must be set to the OFF position.
- Switch OFF by pressing the button again or by swiv-
elling the drive lever out to the paving position.
- On reaching the adjusted material height (material sen-
sor), the filling function is automatically switched off.
f
On actuation, heed danger zones of moving parts of
the vehicle!
68
Set-up mode/
cleaning mode (o)
Detent switch function and LED feedback:
- Set-up mode:
When the vehicle is stationary, this function enables
all operating functions, which are only activated when
the drive lever is swivelled out (vehicle driving), to be
started up.
A
The main function switch must be set to the OFF position.
A
The engine speed is increased to the preselected nom-
inal value.
- Cleaning mode:
After finishing work, this function improves the clean-
ing of the conveying and compacting elements at re-
duced speed:
- Set either auger, conveyor or tamper to "Auto".
- Press button for min. 2 sec. - LED flashes
- Press button again to end cleaning mode.
