FY6600 Series User’s Manual 25
Burst
FY6600 can output waveform with specified number of cycles (called Burst)
from the CH1 channel. FY6600 supports control of burst output by CH2(internal),
manual or external trigger source; The signal generator can generate burst using
Sine wave, Square wave, Ramp wave, Pulse, Noise wave or arbitrary waveform
(except DC).
The instrument supports [CH2], [external] and [manual] three trigger output modes, which
can be selected by the corresponding keys.
Enable Burst Function
Press the front panel BURST button, then press BURS button to enter burst
function. The instrument supports [CH2], [external] and [manual] , three trigger
output modes, which can be selected by the corresponding button. When the
burst function is enabled, press No. button to set the cycles of burst. Use arrow
buttons and ADJ Knob to set the numbers from 1 to 1048575. Then the generator
will output burst waveform according to current configuration.
 NORMAL: The Burst function is disabled。
 CH2 Trigger: CH1 will generate a burst when CH2 generates a pulse.
 Ext. Trigger: CH1 will generate a burst when EXT.IN connector was inputted a
pulse.
 MANU Trigger: User can trigger a burst by pressing ADJ Knob (OK button).
