Technical Specification
Unless specified, all specifications can be guaranteed if the following two
conditions are met.
 The generator has passed self-inspection.
 The generator has been working continuously for at least 30 minutes
under the specified temperature (18℃~28℃).
All the specifications are guaranteed unless those marked with “typical”
Frequency
Model
FY6600-15M
FY6600-30M
FY6600-50M
FY6600-60M
Sine
0~15MHz
0~30MHz
0~50MHz
0~60MHz
Square
0~15MHz
0~25MHz
0~25MHz
0~25MHz
Ramp/Triangle
0~10MHz
0~10MHz
0~10MHz
0~10MHz
Pulse
0~10MHz
0~10MHz
0~10MHz
0~10MHz
TTL/CMOS
0~10MHz
0~10MHz
0~10MHz
0~10MHz
Random
0~10MHz
0~10MHz
0~10MHz
0~10MHz
Minimum
pulse width
20ns(All models of pulse wave minimum width can reach 20ns)
Min. Resolution on
all frequency range
1μHz (Min. resolution can reach 1μHz on all frequency range to
ensure adjusting accuracy under high frequency. For example, it
can output 10.000000000001MHz signal).
Accuracy
±20ppm
Stability
±1ppm/ 3hours
Waveform Characteristics
Waveforms
Sine, Square (Duty Cycle adjustable), Pulse (Pulse width and
cycle time can be set accurately), Triangle/Ramp, Sawtooth
Wave, CMOS, Four channels TTL, DC, Half wave, Full wave,
Positive Step, Inverse Step, Positive Exponent, Inverse Exponent,
Lorenz Pulse, Multitone, Noise, ECG, Trapezoidal Pulse, Sinc
Pulse, Narrow Pulse, Gauss White Noise, AM, FM, and other 64
sets customer-defined waveform.
Arbitrary Wave
Nonvolatile Storage
Can store 64 user-defined arbitrary waveform
Waveform Length
8192 Dots * 14Bit
Sampling Rate
250MSa/s
Vertical Resolution
14 Bits
Sine
Harmonic
Suppression
≥45dBc(<1MHz);≥40dBc(1MHz~20MHz);
