42 FY6600 Series User’s Manual
Total Harmonic
Distortion
<0.8% (20Hz~20kHz,0dBm)
Square
Rise/Fall Time
≤7ns(VPP<5v)
Overshoot
≤5%
Duty Cycle
0.1%~99.9%
Sawtooth
Linearity
≥98% (0.01Hz~10kHz)
Output characteristics
Amplitude（VPP）
Frequency≤10MHz: 1mVpp~20Vpp；
10MHz<Frequency≤20MHz: 1mVpp~10Vpp,
Frequency>20MHz: 1mVpp~5Vpp
Amplitude
Resolution
1mV
Amplitude Stability
±0.5%/ 5 Hours
Amplitude flatness
±5%(<10MHz)；±10%(>10MHz);
Waveform Output
Impedance
50Ω±10%（Typical）
Protection
All channels can work more than 60 seconds when the load is
short-circuited.
Dc Offset
Offset Range
Frequency≤20MHz: ±10V； Frequency>20MHz: ±2.5V
Offset Resolution
1mV
Phase
Feature
Phase range
0~359.9°
Phase resolution
0.1°
TTL Output
Electrical Level
Amplitude
>3Vpp
Fan-out
>8 TTL LOAD
Rise/Fall Time
≤10ns
CMOS Output
Low Electric Level
<0.3V
