FeelTech
FY6600 Series Users Manual 43
High Electric Level
1V~10V
Rise/Fall Time
≤20ns
External Measurement
Frequency Meter
Range
0.01Hz~100MHz
Sensitivity
Gate Time 3 grades(1S, 10S, 100S)
adjustable
Counter
Range
0-4294967295
Coupling
DC , AC
Working Mode
Manual
Voltage Input
Range
2Vpp~20Vpp
Pulse Width
measurement
Resolution 5 nS. Max. 20S
Period
Measurement
Resolution 5nsMax. Limit 20s
Sweep
Sweep Type
Linear or Logarithm
Sweep Objects
Frequency, Amplitude, Offset, Duty Cycle
Sweep Time
0.01S~999.99S/Step
Parameters Range
Starting position and Finishing position can be set arbitrarily.
Sweep Range
Decided by Parameters setting.
VCO
(Voltage Control Output)
Modulation signal
range to input
0~5V
VCO signal
frequency range
0-1000Hz
VCO control object
voltage controlling frequency (VCF), voltage controlling
amplitude (VCA), voltage controlling offset, voltage
controlling duty cycle.
VCO special
function
Can Amplitude Modulate (AM) or Frequency Modulate (FM) by
external analog signal.
Digital Modulation (Modulate analog signal by digit)
Modulation Mode
ASK, FSK, PSK
Signal Carrier
Sine, Square, Triangle/Ramp, Sawtooth, Random (DC excluded)
Source
CH2, External, Manual
Modulation wave
Square with 50% duty cycle (1μHz~10MHz).
Burst Function
