TST Expanded Startup WU
FEIG ELECTRONIC GmbH Page 15 of 18 WU_erweiterte_ Inbetriebnahme4_GB.doc
Value Function Contact
type
End position Hold-open
time
Clear
time
Direction ON
Delay
OFF Delay LCD-Text Test
1401
Safety input stop
during closing (not
switch off able)
N.C. - - Without Without Stop - No
1402
Safety input reversing
during closing (not
switch off able)
N.C. As before As before With Both Without Without Photo eye No
1403
Safety input
Stop during closing
with move on after
releasing th input
N.C. As before As before With Both Without Without Photo eye No
1404
Safety input A
Stop during opening
and closing
N.C. Upper Without With No Without Without Photo eye No
1405
Safety input A
Stop during opening
and closing, after
releasing in closing
the door drives to the
close position.
N.C. Upper Without With No Without Without Photo eye No
1406
Safety input A
Reversing during
opening
N.C. As before As before With Both Without Without Photo eye No
1407
Safety input A
Stop during opening
N.C. As before As before With Both Without Without STOP No
1408
Safety input A
Draw in safety
N.C. As before As before With Both Without Without Feed Retent.
In Door
close
position
